UltraPoE POE-7018 16-Port Gigabit PoE+ Switch with 2 SFP Uplinks, 250W
UltraPoE POE-7018 is a 16-port Gigabit PoE+ switch with two SFP uplinks and a listed 250W shared power budget. It is designed for professional IP surveillance and business networks that need powered Gigabit access ports plus flexible fiber connectivity.
Key features
- 16 x 10/100/1000 Mbps RJ45 PoE ports
- 2 x Gigabit SFP uplink ports
- IEEE 802.3af/at compatibility
- 250W shared total PoE budget
- 36 Gbps switching capacity
- Gigabit packet forwarding for high-definition network video
- Metal rack-mount enclosure with AC power input
Power and compatibility
Each connected device must support IEEE 802.3af or IEEE 802.3at. The 250W rating is the total shared PoE budget, not the output available from every port. No IEEE 802.3bt 90W support is specified for this model.
Typical applications
Suitable for 16-camera IP surveillance networks, business wireless access points, VoIP systems, access control and other compatible Gigabit PoE devices requiring copper access and fiber uplinks.
Frequently asked questions
How many SFP uplinks are included?
The switch provides two Gigabit SFP uplink ports for compatible optical modules.
Are SFP modules included?
No SFP modules are listed as included. Choose compatible modules separately.
Does POE-7018 support PoE++?
No. This listing specifies IEEE 802.3af/at PoE and PoE+. For 90W IEEE 802.3bt devices, use the separate PoE-7018 BT model.
What is the difference between POE-7018 and PoE-7018 BT?
POE-7018 is the 16-port IEEE 802.3af/at model with two SFP uplinks and a listed 250W budget. PoE-7018 BT is a separate high-power model with designated IEEE 802.3bt ports.
