UltraPoE CT-USB-150EX USB over CAT5e/CAT6 Extender – Up to 150 ft
UltraPoE CT-USB-150EX is a two-piece USB extension adapter set designed to carry a USB connection over a separately supplied CAT5e or CAT6 network cable for distances up to 150 ft as listed.
Key Features
- Extends one USB connection over CAT5e or CAT6 cable
- Listed distance up to 150 ft (approximately 45 m)
- Two-piece adapter set with RJ45 link sockets
- USB-A male host-side connector
- USB-A female remote device connector
- Compact inline design with no long fixed extension cable
Product Details
- Brand: UltraPoE
- Model / SKU: CT-USB-150EX
- Host connection: USB-A male
- Remote connection: USB-A female
- Link connection: 2 × RJ45 female
- Required cable: One straight-through CAT5e or CAT6 cable, sold separately
Typical Applications
Suitable for extending compatible low-bandwidth USB peripherals such as keyboards, mice, touch interfaces, and selected USB control devices in classrooms, conference rooms, CCTV control stations, kiosks, and equipment cabinets.
Installation Notes
Connect the USB-A male adapter to the host computer, connect the remote USB device to the USB-A female adapter, and link the two RJ45 sockets with one dedicated CAT5e or CAT6 cable. This is a point-to-point USB extender; do not connect it through an Ethernet switch or IP network.
Frequently Asked Questions
Is the CAT5e/CAT6 cable included?
No network cable is shown with the product; supply a suitable straight-through cable separately.
Can it connect through an Ethernet switch?
No. The RJ45 sockets provide a dedicated point-to-point link and are not standard Ethernet network ports.
What is the maximum distance?
The legacy listing specifies up to 150 ft. Actual performance depends on cable quality, USB device power requirements, and device compatibility.
Will it work with every USB device?
Compatibility is device-dependent. It is best suited to compatible low-bandwidth peripherals; verify support before using storage, cameras, or other higher-bandwidth USB equipment.
