BT90W 16Port AI PoE Switch | IEEE 802.3bt 90W Gigabit for 8K IP PTZ

SKU: PoE-7018 BT

Complies with IEEE 802.3, IEEE 802.3i/u/ab/z
16-Port 10/100/1000Mbps RJ45 supports PoE output
2Port Gigabit RJ45 and 2Port Gigabit Combo for uplink
Complies with IEEE 802.3af/at/bt Power over Ethernet
Support 4Port BT90W PoE output
100-240VAC built-in Power Supply
Auto detects powered device (PD)
Remote power feeding up to 100m
10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Store-and-Forward: wire-speed filtering & forwarding rates
IEEE802.3x Flow control
Made of metal, rack-mount design, with fan cooling
supports one-key function conversion, currently supports 5modes, normal mode, VLAN mode, Extend mode, WATCHDOG mode, QOS mode
Watchdog Mode: PoE port 24-hour AI automatic inspection
VLAN Mode: PoE port are isolated from each other
Extend Mode: PoE port extend to 250meters
QOS Mode: 2 PoE ports to set the priority
Product Manual
Product Spec
