UltraPoE PS-AC10A09UPC 9-Output 24VAC 10A CCTV Power Supply Box
SKU: PS-AC10A09UPCPS-AC10A09UPC is a 9-output 24VAC CCTV power supply box for centralized security-camera power distribution. It delivers 24VAC power with up to 10A total capacity for compatible multi-camera installations.
Key features
- 9 individually protected 24VAC output channels
- 10A / 240W total output capacity
- 100-240VAC, 50/60Hz input
- Resettable PTC protection rated at 1.1A per output
- Individual LED indicators help identify output status
- Thermal cutoff, short-circuit, high-voltage, and overcurrent protection
- Metal enclosure for organized CCTV power distribution
Applications
Suitable for professional 24VAC CCTV cameras and compatible security equipment in retail, commercial, warehouse, school, and perimeter-surveillance installations. Verify the voltage and total current requirement of every connected device before installation.
Specifications
| Model | PS-AC10A09UPC |
| Input | 100-240VAC, 50/60Hz |
| Output | 24VAC +/-5% |
| Total capacity | 10A / 240W maximum |
| Outputs | 9 channels |
| Per-channel protection | 1.1A resettable PTC |
Questions and answers
Which devices can this power box power?
Use it with compatible 24VAC CCTV cameras and security devices. It is not for 12VDC, PoE, or other voltage requirements.
How many cameras can I connect?
The unit has nine output channels. Make sure the total connected load stays within the 10A / 240W maximum.
What happens if one camera cable shorts?
Each channel has independent resettable PTC protection. A faulted output is isolated while the other protected outputs can continue operating; correct the fault before restoring service.
Does the power box need replacement fuses?
No. Its PTC protection resets after the fault condition is cleared.
