UltraPoE POE-3610-8B-4N 10-Port Gigabit Solar Boost PoE Switch
10-Port Gigabit Solar Boost PoE Switch for 12/24V DC Systems
UltraPoE POE-3610-8B-4N is an unmanaged industrial Gigabit switch for solar, battery, vehicle, and remote DC-powered networks. It accepts 12V or 24V DC input for compatible IP cameras, wireless access points, and other edge devices.
Two PoE outputs in one switch
- Ports 1–4: standard IEEE 802.3af/at PoE. The built-in boost circuit raises the 12/24V DC input to approximately 53V DC for compatible standard PoE devices.
- Ports 5–8: passive 12/24V DC PoE for compatible passive equipment.
- Ports 9–10: Gigabit RJ45 uplinks.
Important: Passive PoE does not use IEEE powered-device detection. Confirm device voltage, PoE method, cable pinout, and polarity before connection.
Key Features
- 8 × Gigabit PoE output ports and 2 × Gigabit RJ45 uplinks
- 4 × IEEE 802.3af/at ports, up to 30W per port
- 4 × passive 12/24V DC PoE ports
- 12/24V DC input with DC-to-53V boost for standard PoE
- Plug-and-play unmanaged switching, auto-negotiation, auto MDI/MDI-X
- Fanless metal housing, IP30, reverse-polarity protection
- DIN-rail or wall-mount; −10°C to +60°C operation
Applications
Solar-powered IP cameras, battery-backed wireless access points, RV and vehicle networks, remote gates, off-grid communications, and industrial sites without AC power.
FAQs
Can it power standard 48V PoE cameras or access points?
Yes. Ports 1–4 provide IEEE 802.3af/at PoE from a boosted approximate 53V DC output.
Can it power 24V passive PoE devices?
Yes. Ports 5–8 provide passive 12/24V DC PoE. Verify voltage, polarity, and pinout first.
Does it work with solar batteries?
Yes. It accepts a correctly sized 12V or 24V DC input.
Does it require configuration?
No. It is an unmanaged plug-and-play switch.
Can it be DIN rail mounted?
Yes. DIN-rail and wall-mount installation are supported.
Download: Download the PDF specification sheet.
